8880 Super Car: The best engineered classic Technic set of the 1990s
Posted by FlagsNZ,
For many Technic AFOL enthusiasts, 8880 Super Car marks the pinnacle of what can be achieved with completely brick-built Technic engineering. This set is the flagship Technic set for 1994 and has gone into Technic lore of what can be achieved with good engineering using the original brick-built techniques.
Read on to see how LEGO designed Technic brick-built sets in the 1990s. See how this set incorporated four wheel drive and four wheel steering features, while also having the distinction of being the first Technic set with a V8 engine.
Box/Instructions
As with all significant Technic sets, 8880 Super Car comes in a large box. The front of the box has a great image of the car superimposed over a 1:1 scale profile.
As you can see, my box has seen better days.
The rear of the box shows the B model which is a Formula 1 Car; this could be a stand-alone set by itself.
LEGO used to include a plastic sorting tray with these big boxes. Today, sets come in numbered bags instead. I'm not sure which format I prefer: the numbered bags segregates parts during the build experience when new, but having a sorting tray is a convenient way of making future builds easier to manage.
The instructions are bound in one book. The B model instructions start at the rear cover and work back toward the middle of the book. This set was produced in an age before B model instructions could be downloaded from the Internet.
I have two 8880 Super Cars; one set of instructions has pages 16/17 as a corrected insert. Build step 18 has been corrected by replacing a ball with cross axle with a ball with friction snap as the steering knuckles.
Both of my 8880 Super Cars were bought second hand; however, they have different steering arms: the first set I bought came with the steering arm with pin connection (Part 6540a) on the left, while the second set came with steering arm with axle connection (Part 6540b) on the right. It is this second part which has been inserted as a modification.
The first set I bought also came with three additional grey large steering arms with hub (Part 6540) as spares. I am wondering whether there was some technical design issues with these steering arms and I would like to hear from any members who had this set from new and can shed light on these amendments with the modified page and parts.
There is a mixture of printed parts and stickers. The sticker sheet has an alternative dashboard and Octan sponsorship for the B model - Formula 1 race car.
Parts
There are 1343 parts divided into 36 building steps. This means that there are several steps that have more than 30 parts allocated to them; this is a far cry from today's style of having only a few pieces per building step.
As an example, here is build step 29 which includes 42 pieces.
This set occurred at the watershed from fully brick-built to the more modern studless building techniques. There are several parts unique to this set as well as a few parts that continue to be found in sets over 20 years later.
The build
As stated above, the build is divided into 36 steps. By step 20 the sub-chassis is complete along with the gearbox and steering system.
As this model is four-wheel drive, there are three differentials.
The set uses Technic balls as CV joints in the steering wheel hubs. This is a close up photo of the front steering and suspension assembly. As 5M axles did not appear until 1998, this set has joined a 3M and 2M axle on each of the four drive shafts.
This set uses a chain drive to connect the V8 engine onto the drive train. The steering pinion axle is threaded through the chain. The front steering turns twice as far as the rear by using a 16 tooth pinion at the front and an eight tooth pinion at the rear.
By step 29 the V8 engine is assembled and attached, the steering wheel and Hand of God steering is connected, and the dash board is built complete with dipping head lights.
The standout feature of this set which has not been matched on any other Technic set is the ease in which the gears can be changed. This is achieved by the use of a stick shift plate and Technic stick shift.
These two parts have only been seen in this set. They allow the smoothest gear transitions of any Technic set that I have seen.
The driving ring or synchroniser and axle connector first appeared in 1993 in set 8824 Hovercraft; however, this is the first Technic set to use these parts in a functioning gear box.
Here is a close up photo of the V8 engine, rear suspension and Hand of God steering wheel.
A close up photo of the front suspension.
This set uses toothed half bushes throughout.
These toothed parts first appeared in 1980 and offered some rigid design possibilities. The toothed half bushes suffered from stress fractures and so the toothed system has been withdrawn.
There are a few occasions where the build requires a small amount of force to flex and connect components. Today this would likely be called illegal.
The B Model
As mentioned earlier, the B model is a Formula 1 Car; this could be a stand-alone set by itself.
Half way through the build, the B model chassis is complete.
This model has front wheel steering only: the rear steering arms are rigidly held in place.
The amended instruction page does not include new graphics for the B model's steering arms; I guess that LEGO assumed that customers would recognise that the changes required for the primary model would also be required in the B model. Perhaps there was an amended page for the B model which I have not received.
The sleek Formula 1 race car body work has been enabled with the use of the black hinge plates.
The completed model
The model is finished off with black Technic beams with a sandwich of black and yellow plates that makes the trim. The shape is achieved by the generous use black hinge plates. The entire shaped body is made using these studded brick pieces.
The rear hatch lifts up to reveal the engine. The circular pistons were introduced in 1990 and have been included in a few Technic sets by 1994. A couple of sets had V6 engines but this is the first Technic set to include a V8 engine. This Super Car continues the trend of having the engine at the rear of the car.
Apart from the individual cylinder blocks, the engine itself is fully brick-built.
There is Technic livery with 4x4x4; four wheels with four wheel drive and four wheel steering.
There were several cars in the 1990s that had this configuration, with Toyota Celica and Subaru Alcyone being two examples.
The sleek Formula 1 race car looks great when completed.
The B model has a two speed gear box and the steering is controlled directly from the steering wheel.
Overall opinion
The LEGO Technic designers included a whole lot of engineering into this set and, as such, the set holds a position of awe amongst Technic AFOL enthusiasts.
The instructions do not include any indication for adding a motor although there is plenty of room to add a modern Power Functions M Motor next to the central differential. There is quite a lot of torque between the V8 engine and the wheels so maybe this is why motorisation was not considered.
The suspension is rather stiff but this is handled well by the extremely rigid brick-built chassis. The suspension in the B model is slightly softer due to the shock absorbers being set in at an angle.
I like the fact that the Hand of God steering also operates the principle steering wheel although there is quite a lot of resistance in the steering system if you use the actual steering wheel to turn the car.
The original ball with cross axle steering knuckles often disconnect from the steering arms which is not such a common problem with the modified steering arms with ball with friction snap steering knuckles described above.
Shifting gears is so smooth that it is a shame that LEGO have not used the unique shifter parts in any other set.
There are a couple of STAMPs. The Technic livery with 4x4x4 sticker sits on two 1x8 black tiles. These two parts lie underneath the steering rack of the B model which would wear away the sticker if placed here; I substituted other tiles here to preserve the stickered parts. The Octan livery on the B model is also applied as STAMPs.
The speedo for the A model indicates a speed of 147 km/h (91 mph) which is performance you would expect from a sleek sports car.
This set does reach the upper limit of design possibilities using the traditional brick-built techniques. I can see why Technic evolved over the following few years to include lift arms, panels and flexible hoses.
This set is still available at quite reasonable prices and should be included in any serious Technic enthusiast's collection.
